The LAA250-12-E Aluminum Compression Connector Lug, one hole, is manufactured from high conductivity thick wall aluminum with an enclosed barrel for harsh environments. The color-coded barrels are marked with Panduit and specified competitor die index numbers for proper crimp die selection. Factory pre-filled with joint compound and tin-plated to inhibit corrosion. cULus listed up to 35kV and temperature rated to 90C.
Manuals & Documentation
| Catalog Number | LAA250-12-E |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | India |
| Made in USA | No |
| Color | Red |
| Standard | CSA Certified, UL Listed 486A-486B File #E52164 |
| UPC | 613056857810 |
| GTIN | 00613056857810 |
| Item Type | Compression Lug |
| Stud Size | 1/2 IN |
