NON-90 General Purpose Non-Current Limiting One-Time Fuse, 90 A, 250 V AC/125 V DC, 10/50 kA Interrupt, Class: H, Cartridge Blade Body
- MFR:
- Eaton Bussmann
- MFR #:
- NON-90
- UPC:
- 051712101677
- Item #:
- 798997
NON-90 General Purpose Non-Current Limiting One-Time Fuse, 90 A, 250 V AC/125 V DC, 10/50 kA Interrupt, Class: H, Cartridge Blade Body
- MFR #:
- NON-90
- UPC:
- 051712101677
- Item #:
- 798997
Basic Protection 250Vac (NON) and 600Vac (NOS), 1/8a -600A General Purpose One-time fuses
| Catalog Number | NON-90 |
| Manufacturer | Eaton Bussmann |
| Brand | Eaton Bussmann Series |
| Country of Origin | Mexico |
| Made in USA | No |
| Amperage Rating | 90 |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Connection | Blade end x blade end |
| Interrupt Rating | 10 kAIC at 250 Vac|50 kAIC at 125 Vdc |
| Special Features | Pin-indicating |
| Standard | CE Marked |
| UPC | 051712101677 |
| GTIN | 00051712101677 |
| Item Type | Fuse |
| Weight UOM | Pounds |
| Size | 1.06 In Diameter X 5.88 In Length |
| Voltage Rating | 250 Vac, 125 Vdc |
