9080LBC163101 Power Distribution Block, 600 V AC, 255 A, 1 Pole, 6 AWG to 250 kcmil Wire, Phenolic
- MFR:
- Schneider Electric
- MFR #:
- 9080LBC163101
- UPC:
- 785901097600
- Item #:
- 773026
9080LBC163101 Power Distribution Block, 600 V AC, 255 A, 1 Pole, 6 AWG to 250 kcmil Wire, Phenolic
- MFR #:
- 9080LBC163101
- UPC:
- 785901097600
- Item #:
- 773026
Linergy power distribution blocks are for terminating wires and are designed to NEMA standards. This one pole block has one lug opening on the line (main) side and one lug opening on the load (branch) side. The line side lug is rated to accept one #6 to 250 kcmil copper wire. The load side lug is rated to accept one #6 to 250 kcmil copper wire. The lugs are made of copper. The lugs are rated for 250 amperes with copper wire. The lugs are rated to 600 volts. The housing is made of general purpose phenolic. These Linergy power distribution blocks are UL component recognized and CSA certified.
Manuals & Documentation
| Catalog Number | 9080LBC163101 |
| Manufacturer | Schneider Electric |
| Brand | Square D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| UPC | 785901097600 |
| GTIN | 00785901097600 |
| Width | 1.94 |
| Width UOM | Inch |
| Height | 4.0 |
| Height UOM | Inch |
| Depth | 2.61 IN |
