Eaton Bussmann Series Class J fuse, LPJ, time-delay, dual-element current limiting fuse, 9 A, indicating fuse, interrupting rating of 300 kA at 600 Vac

MFR:
Eaton Bussmann
MFR #:
LPJ-9SPI
UPC:
051712628426
Item #:
772475

Bussmann's UL Class J fuse products extend both our Low-Peak family of products with our LPJ_SP and LPJ_SPI dual-element, time-delay fuses as well as our Limitron line offering fast-acting JKS fuses. The LPJ fuses provide industry leading 300,000 amp interrupting rating at 600Vac RMS Sym and 100kA Vdc while delivering a minimum of 10 seconds of 500 percent rated current ride-through performance which is ideal for sizing of high inrush loads. The LPJ products are available with optional permanent replace fuse indication. These UL Class J products in sizes 1 to 600 amps provide exceptional performance at 600 Vac and 300 Vdc (see spec sheets for specific details) in a compact size rejecting footprint

Catalog Number LPJ-9SPI
Manufacturer Eaton Bussmann
Brand Eaton
Sub Brand Bussmann Series
Country of Origin Mexico
Made in USA No
Amperage Rating 9
Application Ind Facilities & Factories - Facility: Safety and Security Systems
Connection Ferrule end x ferrule end
Interrupt Rating 300 kAIC at 600 Vac|100 kAIC Vdc
Response Time 10 sec at 500%
Special Features Indicating, High in-rush current motor protection
Standard CE Marked,RoHS Compliant
UPC 051712628426
GTIN 00051712628426
Item Type Fuse
Dimensions 2.2500 IN X 0.8100 IN X 0.8100 IN
Size 0.81 In Diameter X 2.25 In Length
Voltage Rating 600 Vac, 300 Vdc
