8536SDO2V02S Type S Magnetic Starter, 110 V AC at 50 Hz, 120 V AC at 60 Hz V Coil, 4 Poles, Open Enclosure
- MFR:
- Schneider Electric
- MFR #:
- 8536SDO2V02S
- UPC:
- 785901455387
- Item #:
- 753829
8536SDO2V02S Type S Magnetic Starter, 110 V AC at 50 Hz, 120 V AC at 60 Hz V Coil, 4 Poles, Open Enclosure
- MFR #:
- 8536SDO2V02S
- UPC:
- 785901455387
- Item #:
- 753829
Type S NEMA motor starters are used for full voltage starting and stopping of AC squirrel cage motors. Type S motor starters have ratings up to 810 amperes. This 4 pole NEMA Size 2 non-reversing starter has a 45 ampere rating. This NEMA Size 2 motor starter has 2 phase ratings of 10 HP at 200 VAC, 15 HP at 230 VAC and 25 HP at 460 and 575 VAC. This non-reversing NEMA motor starter has a melting alloy type overload relay that uses Type B thermal units to sense over current conditions. This NEMA starter has a 5 kA maximum SCCR (Short Circuit Current Rating) per UL508A when protected by an appropriate circuit breaker or fuse. Type S motor starters are available with replaceable coils in a wide variety of voltages. This starter has a 110/120 VAC 50/60 Hz operating coil wired for separate control. This NEMA starter is an open device without an enclosure. This starter is 7.81 inches tall, 5.63 inches wide and 4.94 inches deep. A wide variety of accessories are available for Type S starters. Type S non-reversing NEMA motor starters are UL listed and CSA certified.
| Catalog Number | 8536SDO2V02S |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=519023&lang=en-us |
| UPC | 785901455387 |
| GTIN | 00785901455387 |
