Square D™ Plunger Actuated Limit Switch, Miniature Potted Linear, Series: 9007MS/ML, 240 V AC/28 V DC, 3 A, 1NO-1NC Contact Configuration, 3 A at 240 V AC/5 A at 28 V DC Contact, 1 Pole, Cam/Snap/Lateral Action, Parallel Roller Plunger Spring Return Actuator, M12 Male Connection, NEMA 1/2/4/6/6P/12/13/IP67 Enclosure, Fixed Mounting, 1.56 in W x 0.62 in D x 1.75 in H Size, 10000000 Cycles Operating Cycles, -40 to 220 deg F Operating, Cast Zinc, Epoxy Powder Coated, Environmental Conditions: -40 to 220 deg F Storage Temperature

Manuals & Documentation

Features

  • Linear movement of operating head
  • Form C, snap action silver contacts
  • 5 A 28 VDC, 3 A 120 VAC, 3 A 240 VAC
Manufacturer Part Number 9007MS02S0084
Brand Square D™
Manufacturer Schneider Electric
UPC 785901398967
EAN 0785901398967
Country Of Origin MX
Amperage Rating 3 A
Enclosure Type NEMA 1/2/4/6/6P/12/13/IP67
Finish Epoxy Powder Coated
Material Cast Zinc
Mounting Type Fixed
Series 9007MS/ML
Type Miniature Potted Linear
Voltage Rating 240 V AC/28 V DC
Size 1.56 in W x 0.62 in D x 1.75 in H
Alternative Part Number 8026812
Manufacturer Item Status Active
Country USA
Warranty 18 months
Standards Approvals CE Marked | CENELEC | CSA C22.2 File No. 14 | EN 50041/EN 609475-1 | EN 60204-1 | IEC 60204-1/609475-1 | IEC 60068-2-6 | IEC 60068-2-27 | IEC 60529 | RoHS Compliant | UL 508 | PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP) which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP) which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
Application Material Working, Packaging, Materials Handling, Conveying, Food, Beverage, Mining, Mineral Constructions, Oil and Gas, Crane/Hoisting, Mill and Foundry Applications
Action Cam/Snap/Lateral
Actuator Roller Plunger
Connection Type M12 Male
Contact Configuration 1NO-1NC
Contact Rating 3 A at 240 V AC/5 A at 28 V DC
Environmental Conditions -40 to 220 deg F Storage Temperature
Number Of Poles 1
Operating Cycles 10000000 Cycles
Operating Temperature -40 to 220 deg F
