LC1K1201F7 TeSys K K-Line LC1K IEC Contactor, 110 VAC V Coil, 20 A, 3NO Contact, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- LC1K1201F7
- Item #:
- 671680
LC1K1201F7 TeSys K K-Line LC1K IEC Contactor, 110 VAC V Coil, 20 A, 3NO Contact, 3 Poles
- MFR #:
- LC1K1201F7
- Item #:
- 671680
LC1K1201F7 is a compact 3-pole TeSys K contactor from Schneider Electric for motor applications. Rated 12A AC-3 5.5kW@400V, it includes a 110V 50/60Hz AC coil and 1NC auxiliary contact. LC1K1201F7 is a 3-pole TeSys K contactor from Schneider Electric for simple motor applications rated up to 5.5kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it includes a 110V 50/60Hz AC coil and 1NC built-in auxiliary contact. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 45mm wide, for DIN-rail and panel mounting. Provides a control circuit compatible with 50Hz and 60Hz supplies and 1NC built-in auxiliary contact. Optimized for simple power applications. Can be completed with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K).
Manuals & Documentation
| Catalog Number | LC1K1201F7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Indonesia |
| Made in USA | No |
| Application | Resistive load;motor control |
| Coil Voltage | 110 V AC 50/60 Hz |
| Contact Configuration | 1 NC |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=623234&lang=en-us |
| GTIN | 03389110789638 |
| Item Type | Contactor;LC1K |
