2808G42-00 Type AC Healthcare Facilities Cable With Grounding and Neutral Conductor, Coil Packaging, 600 V AC, (2) 10 AWG Solid Copper Conductor, 250 ft L

MFR:
ATKORE - AFC CABLE
MFR #:
2808G42-00
UPC:
077680163165
Item #:
638532

HCF-Lite, which features interlocked aluminum armor, is a derivative of Type AC Cable. It was introduced in the 1980s to support NEC Article 517 on Healthcare Facilities in "areas of patient care". This branch circuit cable is offered in 12 or 10 AWG THHN in 2, 3, or 4 conductors and was one of the original ColorSpec ID cables. The green interlocked armor became the recognized standard for healthcare facilities' cables, where redundant grounding is required. These 600V cables with THHN conductors have two paths to ground, which is a requirement of NEC 517. The outer metal jacket, in combination with a 16AWG, serves as one equipment grounding means, while the second is an additional full-size green copper ground.

Manuals & Documentation
Catalog Number 2808G42-00
Manufacturer ATKORE - AFC CABLE
Brand AFC Cable Systems
Country of Origin United States
Made in USA Yes
Armour Interlocked Aluminum Strip
Color Green
Conductor Material Copper
Number of Conductors 4
Standard UL 4, 83, 1479, 1581, 2556 File Number E7330, NEC 250.118(8), 300.22(C), 392, 320, 517.13, 518, 645, Federal Specification A-A-59544 (Formerly J-C-30B), Meets OSHA And HUD Requirements, RoHS Compliant
UPC 077680163165
GTIN 00077680163165
Item Type Healthcare Facilities Cable With Ground And Neutral
Length 250
Length UOM Foot
Weight 0.232 LB/FT
Outside Diameter 0.654 IN
Temperature Rating 90
Voltage Rating 600V
