8017630 WM Series 1-Door Compact Non-Disconnect Enclosure, 36 in L x 30 in W x 12 in D, NEMA 12/3R/4X/IP55/IP66 NEMA Rating, 316 Stainless Steel
- MFR:
- Rittal
- MFR #:
- 8017630
- UPC:
- 639889832060
- Item #:
- 626134
8017630 WM Series 1-Door Compact Non-Disconnect Enclosure, 36 in L x 30 in W x 12 in D, NEMA 12/3R/4X/IP55/IP66 NEMA Rating, 316 Stainless Steel
- MFR #:
- 8017630
- UPC:
- 639889832060
- Item #:
- 626134
Compact enclosures WM, material: Door: T316 stainless steel, all-round foamed-in PU seal, Enclosure: T316 stainless steel, surface: Enclosure and door: Brushed, grain 240, Mounting plate: Zinc-plated, supply includes: Enclosure with door(s), L/h door hinge, Mounting plate, Rear wall mounting holes, description: These single door wallmount enclosures can be used for virtually any application. The WM series ensures NEMA protection through a secure locking system, foamed-in-place gasket, and knife-edge sealing surface. Features include a T316 stainless steel body and door, and a zinc plated mounting panel.
Features
- Size: 29.900 Inch Width x 11.800 Inch Depth x 35.400 Inch Height
- One-piece enclosure body
- Left hand hinge
- 2 x 1/4 turn latches with slotted head inserts
- Wallmounting blind-nuts
| Catalog Number | 8017630 |
| Manufacturer | Rittal |
| Brand | Rittal Corp |
| Country of Origin | United States |
| Made in USA | Yes |
| Material | 316 Stainless Steel |
| Mounting | Wall |
| Special Features | Features: 316 Stainless Steel |
| RoHS Indicator | Under Review |
| UPC | 639889832060 |
| GTIN | 00639889832060 |
| Item Type | Wallmount |
| Length | 31.0000 |
| Length UOM | Inch |
| Width | 13.5000 |
| Width UOM | Inch |
| Height | 35.5000 |
| Height UOM | Inch |
| Weight | 122.000 |
| Weight UOM | Pounds |
