| Catalog Number | S11824 |
| Manufacturer | Satco |
| Brand | Satco |
| Country of Origin | China |
| Made in USA | No |
| Application | Ceiling |
| Color | Frost |
| Compatibility | No housing required |
| Finish | White |
| Frequency Rating | 60 HZ |
| Lamp Type | Integrated LED |
| Light Technology | LED |
| Material | Aluminum |
| Special Features | Lumens: 800 ; CCT Range: 2700K/3000K/3500K/4000K/5000K ; CRI: 90 ; Hours Rated: 50000 ; Actual Watts: 10.5 ; Weight: 0.84 lb. ; Safety Listing: cULus ; Location Rating: Damp ; DLC Approved: No ; Energy Star: Yes ; IC Rated: Yes ; Can Size: 5-6 in. ; Trim Type: Gimbal ; Trim Size: 5.2 in. ; Housing Required: No ; Housing Included: No ; Trim Diameter: 7.4 in. ; Trim Width: N/A ; Trim Length: N/A ; Maximum Cutout Size: 5.2 in. ; Ceiling Cutout Height: 7.5 in. ; Material: Aluminum ; Lens Material: Polycarbonate (PC) ; Warranty: 5 Year Limited - Fixtures ; Air Tight: No ; Beam Spread: 90 degrees ; Title 20 Compliant: Yes ; Title 24: California T24 Compliant ; CEC Text: California T24 2016 & 2019 JA8 Compliant T20 Compliant ; Closet Rated: No ; Dimmable: Yes - Dimmable ; FCC Compliant: Yes ; Incandescent Equivalent: 65W ; Indoor/Outdoor Rated: Indoor ; JA8 Compliant: No ; Operating Temperature: -20C (-4F) to a maximum of +40C (+104F) |
| Standard | cULus |
| UPC | 045923118241 |
| GTIN | 00045923118241 |
| Item Type | Retrofits |
| Length | 7.4 |
| Length UOM | Inch |
| Width | 7.4 |
| Width UOM | Inch |
| Height | 3.9 |
| Height UOM | Inch |
| Voltage Rating | 120 |
| Wattage | 11 W |
