YAES14N8 YAES-N Type YAES Standard Insulated Ring Tongue Terminal, 16 to 14 AWG Conductor, Brazed Barrel, Electrolytic Copper, Red
- MFR:
- Burndy, a Hubbell affiliate
- MFR #:
- YAES14N8
- UPC:
- 781810804780
- Item #:
- 591975
YAES14N8 YAES-N Type YAES Standard Insulated Ring Tongue Terminal, 16 to 14 AWG Conductor, Brazed Barrel, Electrolytic Copper, Red
- MFR #:
- YAES14N8
- UPC:
- 781810804780
- Item #:
- 591975
Manuals & Documentation
| Catalog Number | YAES14N8 |
| Manufacturer | Burndy, a Hubbell affiliate |
| Brand | BURNDY |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | For use on copper compression connections |
| Insulation | Y |
| Material | Copper |
| Special Features | Features: An Integral One-Piece Copper Barrel/Insulation Grip And Wire Strain Relief Design: Provides Improved Physical Strength Characteristics Over A Multi-Piece Design, Manufactured Of Pure Electrolytic Copper: Provides Maximum Conductivity, Low Resistance And Ductility For Excellent Crimp Forming Properties, Brazed Seam: Provides A Stronger Barrel Design To Minimize Any Possible Splitting And Eliminates Folding, Deep Inner Barrel Serrations: Provides Excellent Electrical Conductivity And Pullout Strength Values, Smooth Funnel Entry: Easy Wire Insertion, The Insulation Is Locked In Place: Will Not Twist Off, Thereby Maintains Proper Dielectric Values, Electro-Tin Plated: Provides Durable Long-Lasting Resistance To Corrosion, Color-Coded And Clearly Marked: Provides Quick, Easy Wire Size Identification, Ring Tongue: Provides A Secure Termination Under The Screw Head That Can Not Be Removed Without Complete Removal Of The Screw, Two Or More Terminals May Be Stacked On A Common Stud Easily: Provides Flexibility And Versatility, 300 V Maximum, 105 DEG C Maximum, Insulation Diameter (maximum): 0.153 IN, Temperature Rating: 105 DEG C Maximum, Sae-as25036: -108, Package: Bulk, Installation Tool: Non-Ratchet: Y10D, Y10-22 Tool, Ratchet: MR8-83 Tool, Wire Strip Length: 7/32 IN, Color Code: Blue, Finish: Electro-Tin Plated, Wire Insulation Grip: No |
| Standard | UL486;Military Specified (Mil-Spec) |
| UPC | 781810804780 |
| GTIN | 00781810804780 |
| Item Type | YAES |
