FWH-300A North American Style High Speed Fuse, 300 A, 1000 V AC/800 V DC, 200 kAIC Interrupt, Cartridge Body
- MFR:
- Eaton Bussmann
- MFR #:
- FWH-300A
- UPC:
- 051712150163
- Item #:
- 578594
FWH-300A North American Style High Speed Fuse, 300 A, 1000 V AC/800 V DC, 200 kAIC Interrupt, Cartridge Body
- MFR #:
- FWH-300A
- UPC:
- 051712150163
- Item #:
- 578594
High speed fuses provide superior protection or isolation for components such as diodes, silicon controlled rectifiers (SCRs), Gate torn-Off Thyristors (GTOs) and IGBTs and in light and heavy harsh DC traction applications as high as 4000Vdc and 10,000A. Also used for the protection of DC link/power converters. Optimized dimensions and materials allow for excellent thermal dissipation for high current cycling enviroments, or heavy duty applications.
Manuals & Documentation
| Catalog Number | FWH-300A |
| Manufacturer | Eaton Bussmann |
| Brand | Eaton Bussmann Series |
| Country of Origin | Mexico |
| Made in USA | No |
| Amperage Rating | 300 |
| Application | Ind Facilities & Factories - Facility: Safety and Security Systems |
| Connection | Blade end x blade end |
| Interrupt Rating | 200 kAIC at 1000 Vac|50 kAIC at 500 Vdc |
| Mounting | Stud |
| Special Features | Low Arc Voltage, Excellent DC Performance, Superior Cycling Capability |
| Standard | UL Recognized ,CSA Certified,RoHS Compliant,CE Marked |
| UPC | 051712150163 |
| GTIN | 00051712150163 |
| Item Type | High speed fuse |
| Weight UOM | Pounds |
| Size | 1.50 In Diameter X 4.34 In Length |
| Voltage Rating | 1000 Vac, 800 Vdc |
