Telemecanique

XS8C4A1PCN12 XS Series Fixed Rectangular Proximity Sensor, Inductive Sensing, PNP Output, 1NO-1NC Contact, 12 to 48 V DC

MFR:
Telemecanique Sensors
MFR #:
XS8C4A1PCN12
Item #:
550070

The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a 40mm x 40mm x 117mm format sensor, flush mountable in metal. It features a plastic case with a plug-in 5 position turret head and a 1/2 NPT cable entry. It has a sensing distance of 20mm. Four-wire, DC supply, 12V to 48V, NO and NC function, PNP discrete output.

Manuals & Documentation
Catalog Number XS8C4A1PCN12
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Application Mobile equipment
Connection Screw Clamp Terminal
Connector Screw-clamp terminals, 4 x 1.5 mm²
Enclosure PBT
Frequency Response <=300 Hz
Indicator Supply on 1 LED green);output state 1 LED yellow)
Material Plastic
Mounting Flush
Output 4-Wire, PNP, DC
Response Time
Sensing Distance 20 mm
Sensing Range 20 MM,> 0.59...1.57 IN (> 15...40 MM)
Sensor 40 MM,40 MM,INDUCTIVE PROXIMITY SENSOR
Special Features PLASTIC
Standard IP67 conforming to IEC 60529;IP65 conforming to IEC 60529;IP69K conforming to DIN 40050;CE
Supply Voltage 12...48 V DC reverse polarity protection
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=181658555&lang=en-us
GTIN 03389119058261
Item Type Inductive proximity sensor;Form 40 x 40 x 117
Size 40 mm Length x 117 mm Width x 40 mm Height
Operating Temperature -25-70 A Degrees C
Voltage Rating 12 - 48 Volt
