8018796 TS8 Baying Enclosure System With Door, 12 in Leg Kit, 63 in W x 12 in D, NEMA 1/3R/12/IP55 NEMA Rating, Sheet Steel
- MFR:
- Rittal
- MFR #:
- 8018796
- UPC:
- 639889843622
- Item #:
- 529192
8018796 TS8 Baying Enclosure System With Door, 12 in Leg Kit, 63 in W x 12 in D, NEMA 1/3R/12/IP55 NEMA Rating, Sheet Steel
- MFR #:
- 8018796
- UPC:
- 639889843622
- Item #:
- 529192
Floor mount TS 8 enclosure, material: Enclosure frame: Sheet steel, 1.5 mm, Roof: Sheet steel, 1.5 mm, Door: Sheet steel, 2.0 mm, Rear panel: Sheet steel, 1.5 mm, Side panel: Sheet steel, 1.5 mm, Mounting plate, 3.0mm Zinc-plated, surface: Enclosure frame: Dipcoat-primed, Door, roof, rear panel and side panel: Dipcoat-primed, powder-coated on the outside, textured paint, color: RAL 7035, Mounting plate, Zinc-plated, supply includes: Enclosure frame, Door(s), Roof plate, Rear panel, Side panel, Mounting plate, 4 eyebolts, Lock: 3 mm double-bit, description: Floor mount TS 8 with mounting plate. Protection category IP 55. Roof, rear panel and side panel are internallt fastened for added security. Includes pre-mounted 12 floor stand kit.
Features
- Dimension: 63 Inch Width x 11.800 Inch Depth
- 12 Inch removable floor stands
- Fully depth adjustable mounting panel included
| Catalog Number | 8018796 |
| Manufacturer | Rittal |
| Brand | Rittal Corp |
| Country of Origin | United States |
| Made in USA | Yes |
| Color | Light Gray |
| Material | Sheet Steel |
| RoHS Indicator | Under Review |
| UPC | 639889843622 |
| GTIN | 00639889843622 |
| Item Type | Freestanding Enclosure |
| Length | 88.0000 |
| Length UOM | Inch |
| Width | 36.0000 |
| Width UOM | Inch |
| Height | 78.0000 |
| Height UOM | Inch |
| Weight | 452.000 |
| Weight UOM | Pounds |
