8018627 WM Series 1-Door Compact Disconnect Enclosure, 24 in L x 26 in W x 8 in D, NEMA 12/3R/4X/IP55/IP66 NEMA Rating, 304 Stainless Steel
- MFR:
- Rittal
- MFR #:
- 8018627
- UPC:
- 639889839458
- Item #:
- 474328
8018627 WM Series 1-Door Compact Disconnect Enclosure, 24 in L x 26 in W x 8 in D, NEMA 12/3R/4X/IP55/IP66 NEMA Rating, 304 Stainless Steel
- MFR #:
- 8018627
- UPC:
- 639889839458
- Item #:
- 474328
Compact enclosures WM, Stainless steel, isolator door locking, material: Door: Stainless steel, all-round foamed-in PU seal, Enclosure and door: Stainless steel 1.4301 (AISI 304), Mounting plate: Sheet steel, zinc-plated, surface: Brushed, supply includes: Enclosure with door, L/h door hinge, Wall mounting blind nut, Gland door with universal cut-out for disconnectable circuit, description: These flange mount disconnect wallmount enclosures can be used for virtually any application. The WM series ensures NEMA protection through a secure locking system, foamed-in-place gasket, and knife-edge sealing surface. Features include a stainless steel body and door, and a zinc plated mounting panel.
| Catalog Number | 8018627 |
| Manufacturer | Rittal |
| Brand | Rittal Corp |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Industrial |
| Construction | One Piece Construction |
| Insulation | Foamed-in PU Seal |
| Material | Stainless Steel |
| Mounting | Wall |
| NEMA Rating | 4X |
| Special Features | Features: Flange Door with Universal Disconnect Cutout |
| Standard | UL Listed, cUL Listed |
| RoHS Indicator | Yes |
| UPC | 639889839458 |
| GTIN | 00639889839458 |
| Item Type | Compact Enclosure |
| Length | 24.3800 |
| Length UOM | Inch |
| Width | 9.3800 |
| Width UOM | Inch |
| Height | 28.1300 |
| Height UOM | Inch |
| Weight | 97.000 |
| Weight UOM | Pounds |
| Size | 24 (H) x 26 (W) x 8.3 (D) |
