SQUARE D

EJB14040 Miniature Circuit Breaker, 40 Amp, 1 Pole, 277V

MFR:
Schneider Electric
MFR #:
EJB14040
UPC:
785901130543
Item #:
434872

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 40A, 1 pole, and has an operating voltage of 277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 630A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 1800A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.

Manuals & Documentation
Catalog Number EJB14040
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Application NF panelboard;HID rated;HACR rated
Connection Lugs aluminium;AWG 12...AWG 2/0 aluminium;AWG 14...AWG 2/0 copper
Special Features Trip indicator
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423254691&lang=en-us
UPC 785901130543
GTIN 00785901130543
Item Type Miniature circuit-breaker
Width 0.980000000000000
Width UOM Inch
Height 5.660000000000000
Height UOM Inch
Depth 4.05 IN
Trip Type Thermal-magnetic
Voltage Rating 277 V AC
