The female disconnect is made of brass and is tin-plated. It is fully insulated in blue heat shrink. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 16-14 AWG (1.5-2.6 mm). It is 1.44 (36.6 mm) long and 0.35 (8.9 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bags of 25.
Manuals & Documentation
| Catalog Number | DNH14-250FIB-Q |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | United States |
| Made in USA | Yes |
| Color | Blue |
| Connection | Standard |
| Finish | Tin-Plated |
| Insulation | Heat Shrink - Fully Insulated |
| Material | Brass |
| Standard | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| UPC | 074983818297 |
| GTIN | 00074983818297 |
| Item Type | Disconnect |
| Temperature Rating | 230 Degrees Fahrenheit (110 Degrees Celsius) |
| Voltage Rating | 600 |
| Wire Size | #14 AWG |
