PCSB4-3S-12Y Pan-Lug 3-Port Single Sided Multi-Tap Connector, 14 to 4 AWG Stranded, 14 to 10 AWG Aluminum/Copper/Solid Solid/Stranded Conductor, Screw Installation, Aluminum/PVC
- MFR:
- Panduit
- MFR #:
- PCSB4-3S-12Y
- UPC:
- 074983597574
- Item #:
- 401838
PCSB4-3S-12Y Pan-Lug 3-Port Single Sided Multi-Tap Connector, 14 to 4 AWG Stranded, 14 to 10 AWG Aluminum/Copper/Solid Solid/Stranded Conductor, Screw Installation, Aluminum/PVC
- MFR #:
- PCSB4-3S-12Y
- UPC:
- 074983597574
- Item #:
- 401838
The PCSB4-3S-12Y Multi-Tap Mechanical Lug has a flexible design that can be used as a tap, splice, or dead-end Lug. Made from high strength, extruded aluminum alloy to provide premium electrical and mechanical performance. Insulated with clear PVC to eliminate the need for taping and allow for visual inspection of the complete conductor insertion. UL Listed and CSA Certified.
Manuals & Documentation
| Catalog Number | PCSB4-3S-12Y |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Aluminum or Copper Code Conductors |
| Insulation | Clear PVC |
| Material | Aluminum / Clear PVC |
| Standard | UL listed and CSA certified for use up to 600V & Temperature Rated to 90 Degrees C |
| UPC | 074983597574 |
| GTIN | 00074983597574 |
| Item Type | Single-Sided Multi-Tap Connector |
| Voltage Rating | 600 |
