LB6X-100M Type LB Mogul Conduit Body, 1 in Hub, 31 cu-in Capacity, Malleable Iron, Electro-Zinc Plated/Dichromate/Epoxy Powder Coated
- MFR:
- O-Z/Gedney
- MFR #:
- LB6X-100M
- UPC:
- 783126013443
- Item #:
- 397516
LB6X-100M Type LB Mogul Conduit Body, 1 in Hub, 31 cu-in Capacity, Malleable Iron, Electro-Zinc Plated/Dichromate/Epoxy Powder Coated
- MFR #:
- LB6X-100M
- UPC:
- 783126013443
- Item #:
- 397516
Manuals & Documentation
| Catalog Number | LB6X-100M |
| Manufacturer | O-Z/Gedney |
| Brand | O-Z/Gedney |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | For Rigid Conduit And IMC |
| Connection | Tapered FNPT |
| Finish | Triple coat: Zinc Electroplated, Dichromate, Epoxy Powder Coat |
| Hub Size | 1 IN |
| Material | Malleable Iron |
| Special Features | Serve as pulling fittings; Make bends in conduit system; Provide openings for splicing; Connect and change direction of conduit runs; Allow connections for branch runs; Permit access to conductors for maintenance; Tapered threaded hubs (NPT); Raintight when used with gasketed covers; Smooth integral hub bushings protect conductor insulation; Suitable for wet locations when used with gasketed covers; Supplied completely assembled with cover, gasket and captive stainless steel screws; Meets NEC section 314.28 rule; Neoprene gaskets; Replacement covers and gaskets available |
| Standard | Third Party Certification: UL File Number E-18095, CSA 009795, Applicable Third Party Standards: UL 514A, CSA C22.2 No.18, Federal Specification Number A-A-50563, Hazardous Locations: Class 1, Division 2 Per NEC Section 501-4(B), NEMA : FB-1, FB-2.10 |
| UPC | 783126013443 |
| GTIN | 00783126013443 |
| Item Type | Type LB Mogul Conduit Body |
| Length | 8.94 |
| Width | 2.38 |
| Height | 3.63 |
