SQUARE D

8502SDO1V02S Type S 1-Phase Contactor, 110/120 V AC V Coil, 2 Poles

MFR:
Schneider Electric
MFR #:
8502SDO1V02S
UPC:
785901774037
Item #:
390367

Type S non-reversing magnetic contactors are used to switch heating loads, capacitors, transformers, and electric motors where overload protection is provided separately. Type S contactors have ratings up to 810 amperes. This 2 pole NEMA Size 2 non-reversing contactor has a 45 ampere rating. Single phase NEMA Size 2 contactors have 3 HP at 115 VAC and 7.5 HP at 230 VAC ratings. This NEMA contactor has a 100 kA maximum SCCR rating per UL508A when protected by an appropriate circuit breaker or fuse. These contactors are available with replaceable coils in a wide variety of voltages. This contactor has a 110/120 VAC 50/60 Hz coil that is wired for separate control. This NEMA contactor is an open device without an enclosure. This contactor is 5.13 inches tall, 4.31 inches wide and 4.94 inches deep. A wide variety of accessories are available for Type S contactors. Type S NEMA contactors are UL listed and CSA certified.

Manuals & Documentation
Catalog Number 8502SDO1V02S
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Application Non-reversing;Circuit-breaker 100 A maximum, SCCR: 100 kA at 480 V AC;fuse J 100 A maximum, SCCR: 100 kA at 600 V AC;fuse T 100 A maximum, SCCR: 100 kA at 600 V AC;fuse RK1 100 A maximum, SCCR: 100 kA at 600 V AC;fuse RK5 100 A maximum, SCCR: 100 kA at 600 V AC
Coil Voltage 120 V AC 60 Hz;110 V AC 50 Hz
Connection Screw clamp terminals
Contact Configuration Without
Indicator No indicator
Phase 1
Special Features Separate control circuit
UPC 785901774037
GTIN 00785901774037
Item Type Contactor;No control units
Cross Reference Products Eaton C10DN2AB|Eaton CN15GN2AB|Grainger 1H461|Schneider 8502SDO1V02S|Siemens 40FP32AA|SquareD 8502SDO1V02S
