Pressure switch 9012G, fixed scale, 1 threshold, 1.5 to 75 PSIG
- MFR:
- Schneider Electric
- MFR #:
- 9012GRG4
- UPC:
- 785901476511
- Item #:
- 383786
Pressure switch 9012G, fixed scale, 1 threshold, 1.5 to 75 PSIG
- MFR #:
- 9012GRG4
- UPC:
- 785901476511
- Item #:
- 383786
Pressure switches, float switches, vacuum switches and power pressure switches for control or monitoring of water pumps, compressors, agricultural/irrigation water systems, molding presses, injection molders, grinding machines, machining centers, complex, special machines, HVAC, automotive, food, beverage, healthcare facilities, pharmaceutical and more. Classes 9012, 9013, 9016, 9036, 9037 and 9038.
Manuals & Documentation
Features
- 9012G industrial pressure switches control circuit rated for pneumatic and hydraulic systems
- Rugged, robust construction provides a long life and provides years of uninterrupted, worry-free service
- Driftproof cut-in and cut-out settings
- Has visible vertical contacts, easy to inspect without removal
- An extra strong frame that resists distortion when mounting the switch to a compressor
- Designed for the direct control of motors in pump and compressor applications
- For use in sensitive pressure control application
- 1/4-18 NPTF pressure
- Fixed differential
- 1/2 in NPT conduit entrance cable entry
| Manufacturer Part Number | 9012GRG4 |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| UPC | 785901476511 |
| EAN | 0785901476511 |
| Country Of Origin | MX |
| Enclosure Type | NEMA 1 |
| Housing Material | Die Cast Aluminum |
| Series | 9012G |
| Temperature Rating | -10 to 185 deg F |
| Type | Electromechanical Low Pressure Single Stage |
| Alternative Part Number | 8060679 |
| Manufacturer Item Status | Active |
| Country | USA |
| Warranty | 18 months |
| Standards Approvals | ECCN: EAR99 | CE Marked | CSA C22.2 File No 14/LR26817 Class 3218 02 | IEC 68-2-6/58-2-27 | REACH Compliant | UL 50/508/File No E12158 CCN NKPZ | PROP65: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other Reproductive harm. For more information go to www.p65warnings.ca.gov |
| Application | Industrial, Pressure Control, Monitoring of Water Pumps, Compressors, Agricultural/Irrigation Water Systems, Molding Presses, Injection Molders, Grinding Machines, Machining Centers, Complex/Special Machines, HVAC, Automotive, Food, Beverage, Healthcare Facilities and Pharmaceutical Applications and Regulation Between 2 Thresholds |
| Connection Material | Steel/Nitrile |
| Connection Type | NPT Conduit/Screw Clamp |
| Contact Configuration | 1NO-1NC |
| Diaphragm Material | Nitrile |
| Differential | 2.2 psi |
| Maximum Pressure | 240 psi |
| Operating Cycles | 120 cpm |
| Pressure Rating | 1.5 to 75 psi |
