270F Wedge-Lok Blank Clip Cover, 3/4 in Hub, For Use With Form 7 UNILETS Conduit Outlet Body, Cast Grayloy Iron, Triple Coated
- MFR:
- Appleton Electric
- MFR #:
- 270F
- UPC:
- 781381507523
- Item #:
- 381796
270F Wedge-Lok Blank Clip Cover, 3/4 in Hub, For Use With Form 7 UNILETS Conduit Outlet Body, Cast Grayloy Iron, Triple Coated
- MFR #:
- 270F
- UPC:
- 781381507523
- Item #:
- 381796
FM7 Wedge-Lok Blank Clip Cover With Screw, Hub Size: 3/4 IN, Form: 7, Mounting: Screw-In, Material: Cast Grayloy-Iron, Finish: Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat), Color: Gray, Standard: UL 514A, UL 514B, UL File
Manuals & Documentation
| Catalog Number | 270F |
| Manufacturer | Appleton Electric |
| Brand | Appleton |
| Country of Origin | Mexico |
| Made in USA | No |
| Application | For FM7 Unilet Conduit Outlet Bodies |
| Color | Gray |
| Finish | Triple-Coat (Zinc Electroplate, Chromate And Epoxy Powder Coat) |
| Form | 7 |
| Hub Size | 3/4 IN |
| Material | Cast Grayloy-Iron |
| Mounting | Screw |
| Special Features | Unique Wedge-Lok clip cover design allows easy removal without damaging the conduit body; Approved for use in wet locations; The cover is secured with clips, not screws; Stainless steel screws; Wiring capacity: 0.8 CU-IN as per NEC 314.16(A) |
| Standard | UL 514A, UL 514B, UL File Number E2527, CSA C22.2 No. 18.3, CSA 065183, NEMA FB-1 |
| UPC | 781381507523 |
| GTIN | 00781381507523 |
| Item Type | Blank Clip Cover With Screw |
