QC05ERCB Universal Commercial Encapsulated Buck Boost Transformer, 120/240 V AC Primary, 12/24 VAC Secondary, 50 VA Power Rating, 50/60 Hz, 1 Phase
- MFR:
- Hammond Power Solutions
- MFR #:
- QC05ERCB
- UPC:
- 803423042189
- Item #:
- 366479
QC05ERCB Universal Commercial Encapsulated Buck Boost Transformer, 120/240 V AC Primary, 12/24 VAC Secondary, 50 VA Power Rating, 50/60 Hz, 1 Phase
- MFR #:
- QC05ERCB
- UPC:
- 803423042189
- Item #:
- 366479
Manuals & Documentation
| Catalog Number | QC05ERCB |
| Manufacturer | Hammond Power Solutions |
| Brand | HPS |
| Country of Origin | Canada |
| Made in USA | No |
| Application | General purpose for raising supply voltage caused by line drop or equipment demand on the distribution system, or lower voltage caused by increased system voltages due to supply line adjustments |
| Enclosure | NQ0-N3R - Indoor or Outdoor |
| Frequency Rating | 50/60 HZ |
| Mounting | Wall |
| Special Features | Encapsulated transformers can be used to buck and boost voltage in single and three phase applications where supply voltages are frequently above or below nominal. These transformers can also be used in low voltage transformer application. |
| Standard | CSA, UL, Class 1 Div II |
| UPC | 803423042189 |
| GTIN | 00803423042189 |
| Item Type | Transformer > Dry Type > Buck-Boost |
| Length | 5.06 |
| Length UOM | Inch |
| Width | 3.69 |
| Width UOM | Inch |
| Height | 7.19 |
| Height UOM | Inch |
| Temperature Rating | Typical 30 Average/ 40 Maximum DEG C |
| Cross Reference Products | Acme T181047|ConnElect SB12N050F|Dongan 3505M|Dongan 35M005|Eaton J050A1EA1A01|Eaton S10N04A81N|FederalPac SB12N.050F|GEIndust 9T51B0102|Grainger 2CN44|HammondPwr EE2E |
