HGL26070 I-Line PowerPact H Type HGL Molded Case Circuit Breaker, 600 V AC/250 to 500 V DC, 70 A, 18/20/35/65 kA Interrupt, 2 Poles, Thermal Magnetic Trip
- MFR:
- Schneider Electric
- MFR #:
- HGL26070
- UPC:
- 785901598800
- Item #:
- 346018
HGL26070 I-Line PowerPact H Type HGL Molded Case Circuit Breaker, 600 V AC/250 to 500 V DC, 70 A, 18/20/35/65 kA Interrupt, 2 Poles, Thermal Magnetic Trip
- MFR #:
- HGL26070
- UPC:
- 785901598800
- Item #:
- 346018
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 70A, 2 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Manuals & Documentation
| Catalog Number | HGL26070 |
| Manufacturer | Schneider Electric |
| Brand | SQUARE D |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | United States |
| Made in USA | Yes |
| Color | Black |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422647&lang=en-us |
| UPC | 785901598800 |
| GTIN | 00785901598800 |
