LIMIT SWITCH PLUG IN UNIT 600V 10AMP C

Manuals & Documentation
Catalog Number 9007CO68
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin France
Made in USA No
Action Snap action
Amperage Rating 10
Application 9007C
Contact Configuration 2(NC-NO);Form Z
Contact Rating NEMA A600/R300
Enclosure NEMA 1 NEMA TYPE 250-NEMA 2 NEMA TYPE 250-NEMA 4 NEMA TYPE 250-NEMA 6 NEMA TYPE 250-NEMA 6P NEMA TYPE 250-NEMA 12 NEMA TYPE 250-NEMA 13 NEMA TYPE 250
Number of Poles 2
Operating Cycles 1000000 CYCLES
Special Features NEUTRAL POSITION,STANDARD PLUG-IN
Standard 25 GN 10-150 HZ)IEC 60068-2-6,60 GN 9 MS IEC 60068-2-27,IP67 IEC 60529,CLASS 0 IEC 61140
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=376609&lang=en-us
UPC 785901812050
GTIN 00785901812050
Item Type Limit switch plug-in unit
Size 1.79
Environmental Conditions Standard environment
Operating Temperature -20-185 A Degrees F STANDARD ENVIRONMENT
Voltage Rating 1.2 A 600 V AC, A600 NEMA RATING DESIGNATION-1.5 A 480 V AC, A600 NEMA RATING DESIGNATION-3 A 240 V AC, A600 NEMA RATING DESIGNATION-6 A 120 V AC, A600 NEMA RATING DESIGNATION-0.11 A 250 V DC, R300 NEMA RATING DESIGNATION-0.55 A 125 V DC, R300 NEMA RATING DESIGNATION
