ZCMD21C12 ZCMD 2-Pole Fixed Limit Switch Body, 1NO-1NC Contact, For Use With XCMD and ZCMD Series Standard Format Limit Switch, 4 A Contact
- MFR:
- Telemecanique Sensors
- MFR #:
- ZCMD21C12
- UPC:
- 785901630388
- Item #:
- 310288
ZCMD21C12 ZCMD 2-Pole Fixed Limit Switch Body, 1NO-1NC Contact, For Use With XCMD and ZCMD Series Standard Format Limit Switch, 4 A Contact
- MFR #:
- ZCMD21C12
- UPC:
- 785901630388
- Item #:
- 310288
This ZCM body/contact assembly with connector has standard contacts and a Zamak body. It has 1 x NO + 1 x NC snap action contacts and a M12 5-pin connector. It can be matched with any head, actuator or connector from the XCKD, XCKP and XCKT ranges.
Manuals & Documentation
| Catalog Number | ZCMD21C12 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Mexico |
| Made in USA | No |
| Action | Snap action |
| Amperage Rating | 4 |
| Application | XCMD |
| Connection | Male connector M12, 5 pins |
| Contact Configuration | 1 NC + 1 NO |
| Number of Poles | 2 |
| Operating Cycles | 5000000 CYCLES, DC-13 24 V, 3 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 2 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C |
| Special Features | FIXED |
| Standard | IEC, UL LISTED, CSA |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=880298&lang=en-us |
| UPC | 785901630388 |
| GTIN | 03389110299120 |
| Item Type | Limit switch body |
| Size | 16 MM,30 MM,50-50 MM |
| Voltage Rating | 0.22 A 50 V, DC-13 EN/IEC 60947-5-1 APPENDIX A-3 A 50 V, AC-15 EN/IEC 60947-5-1 APPENDIX A |
