The vibration resistant male tab disconnect is made of copper and is nickel-plated. It is fully insulated in a yellow, oversized nylon housing. It has a tab size of 0.250 x 0.032 (6.3 x 0.8 mm) and supports a wire range of 12-10 AWG (4.0-6.0 mm). It is 0.96 (24.4 mm) long and 0.22 (5.6 mm) wide. The disconnect has a standard barrel configuration and a butted seam barrel. It comes in bottles of 25.
Manuals & Documentation
| Catalog Number | DNF10-250FIMB-Q |
| Manufacturer | Panduit |
| Brand | Panduit |
| Country of Origin | Mexico |
| Made in USA | No |
| Color | Yellow |
| Connection | Standard |
| Finish | Nickel-Plated |
| Insulation | Nylon |
| Material | Copper |
| Standard | UL 310 Listed, UL Listed 20H3 E78522; CSA Certified LR31212, C22.2 No.153 |
| UPC | 074983119028 |
| GTIN | 00074983119028 |
| Item Type | Disconnect |
| Temperature Rating | 221 Degrees Fahrenheit (105 Degrees Celsius) |
| Voltage Rating | 600 |
| Wire Size | #10 AWG |
| Cross Reference Products | 3M 73M-250-32-NBL|3M MNG10-250DMIX|ABBInstall 10RC-251T|ABBInstall 251T|ABBInstall RC25177|ABBInstall TNF10-250MD|ABBInstall TNF10250MDDXV|Burndy FQN10M25X03D|Burndy NQ10M250D|Grainger 5X429 |
