7715535 EL Series Enclosure, 29 in L x 24 in W x 26 in D, NEMA IP54, Carbon Steel
- MFR:
- Rittal
- MFR #:
- 7715535
- UPC:
- 639889850668
- Item #:
- 305928
7715535 EL Series Enclosure, 29 in L x 24 in W x 26 in D, NEMA IP54, Carbon Steel
- MFR #:
- 7715535
- UPC:
- 639889850668
- Item #:
- 305928
Wall-mounted enclosures EL, 3-part, pre-configured with mounting angles, depth-variable, Pre-configured, material: Wall and hinged part: Sheet steel, 1.5 mm, Viewing window: Single-pane safety glass, 3 mm, surface: Powder-coated, color: Wall and hinged part: RAL 7035, Glazed door: RAL 7035/7015 (slate grey), supply includes: Wall section, Hinged part with 25 mm pitch pattern of holes in the front and rear frame, Designer glazed door, description: Wall-mounted enclosure 3-part, pre-configured with: Solid gland plate, top, with brush strip at the bottom, mounting rails, C rails, outlet filter, earth rail, wall-mounting bracket
Features
- Size: 23.600 Inch Width x 26.500 Inch Depth x 29.400 Inch Height
- Separate, swing-out center section for front and rear component access
- Sturdy design provides solid support for equipment
- Wall mountable design
| Catalog Number | 7715535 |
| Manufacturer | Rittal |
| Brand | Rittal Corp |
| Country of Origin | United Kingdom |
| Made in USA | No |
| Application | Industrial |
| Color | RAL 7035, RAL 7015 |
| Material | Sheet Steel |
| Mounting | Wall |
| Special Features | Features: Hinged Door Provides Optimum Accessibility, Safety Glass Viewing Window |
| Standard | UL Listed, cUL Listed |
| RoHS Indicator | Yes |
| UPC | 639889850668 |
| GTIN | 00639889850668 |
| Item Type | 3 Part EL Compact Enclosure |
| Length | 29.1340 |
| Length UOM | Inch |
| Width | 30.7090 |
| Width UOM | Inch |
| Height | 24.8030 |
| Height UOM | Inch |
| Weight | 111.111 |
| Weight UOM | Pounds |
| Size | 746 (H) x 600 (W) x 673 (D) |
