YA8CL2TC10 YA-L-2TC 2-Hole Compression Lug With Inspection Window, 8 AWG Solid/Stranded Copper Conductor, Die Code: 49, #8 to #10 Stud, Electro Plated Tin Copper
- MFR:
- Burndy, a Hubbell affiliate
- MFR #:
- YA8CL2TC10
- UPC:
- 781810503584
- Item #:
- 289621
YA8CL2TC10 YA-L-2TC 2-Hole Compression Lug With Inspection Window, 8 AWG Solid/Stranded Copper Conductor, Die Code: 49, #8 to #10 Stud, Electro Plated Tin Copper
- MFR #:
- YA8CL2TC10
- UPC:
- 781810503584
- Item #:
- 289621
Manuals & Documentation
| Catalog Number | YA8CL2TC10 |
| Manufacturer | Burndy, a Hubbell affiliate |
| Brand | BURNDY |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | Wire Termination |
| Material | COPPER |
| Special Features | Features: UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Tongue Angle: Straight, Temperature Rating: 90 DEG C, Die Index: 49, Finish: Electro-Tin Plated, Wire Strip Length: 1/2 IN, Color Code: Red, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W8CVT, W8CRT, X8CRT Die, (1), Hydraulic: BCT500HS, Y500CTHS Tool, W8CVT, W8CRT, X8CRT Die, (1), Y35, Y39, Y750, PAT750 Tool, U8CRT Die, (1), Y46 Tool, U8CRT Die With PUADP-1 Adapter, (1), Conductor Type: Commercial Stranded Copper, Flexible Copper, Solid Copper, Dieless Tools (number Of Crimps): Y81KFT, Y81KFTMBH, Y1MRTC, Y8MRB-1, PAT81KFT-18V, MY29-3, MY29-11, MRC840 Tool, (1) |
| Standard | UL 486A-486B |
| UPC | 781810503584 |
| GTIN | 00781810503584 |
| Item Type | Standard Barrel, Tin Plated |
| Voltage Rating | 35 |
