Telemecanique

XS108B3NAM12 OsiSense Cylindrical Fixed Form Proximity Sensor, Inductive, NPN/Discrete Output, 1NO Contact, 12 to 24 V DC

MFR:
Telemecanique Sensors
MFR #:
XS108B3NAM12
Item #:
279608

The XS range is an offer of inductive proximity sensors for the detection, without physical contact, of metal objects. The advantages of inductive detection are numerous, no physical contact with the object to be detected. Thus avoiding wear and enabling detection of fragile or freshly painted objects. High operating rates. Fast response. Excellent resistance to industrial environments (robust products, fully encapsulated in resin). This product is a cylindrical, increased range, flush mountable sensor. Diameter 8mm, threaded M8 x 1. It features a nickel plated brass cylindrical short case boby and a M12 connector. It has a sensing distance of 2.5mm. Three-wire, DC supply, 12V to 24V, NO function, NPN solid-state output .

Manuals & Documentation
Catalog Number XS108B3NAM12
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Indonesia
Made in USA No
Application -
Connector Male connector M12, 4 pins
Enclosure Stainless steel 303
Indicator Output state 1 LED yellow)
Material Metal
Mounting Flush
Sensing Range > 0...0.1 IN (> 0...2.5 MM)
Special Features IP65 CONFORMING TO IEC 60529-IP67 CONFORMING TO IEC 60529,M12 MALE CONNECTOR, 4 PINS
Standard IP65 conforming to IEC 60529;IP67 conforming to IEC 60529;CE
Supply Voltage 12...24 V DC reverse polarity protection
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=865704&lang=en-us
GTIN 03389119036115
Item Type Inductive proximity sensor;Cylindrical M8
Operating Temperature -25-70 A Degrees C
