LP5K0910BW3 TeSys K LP5K Reversing Miniature IEC Contactor, 24 V DC V Coil, 9/16/20 A, 3NO Contact, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- LP5K0910BW3
- Item #:
- 273842
LP5K0910BW3 TeSys K LP5K Reversing Miniature IEC Contactor, 24 V DC V Coil, 9/16/20 A, 3NO Contact, 3 Poles
- MFR #:
- LP5K0910BW3
- Item #:
- 273842
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 9A/690V AC-3 (4kW@400V). It provides low consumption 24V DC coils with transient suppressor module, 2NO built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC).
Manuals & Documentation
| Catalog Number | LP5K0910BW3 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=639738&lang=en-us |
| GTIN | 03389110501827 |
