SQUARE D

MJL36350 Molded Case Circuit Breaker, 350 Amp, 3 Pole, 600V

MFR:
Schneider Electric
MFR #:
MJL36350
UPC:
785901879947
Item #:
264974

PowerPacTM-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT M-Frame circuit breakers have either a fixed long time electronic trip unit or an adjustable amperage version. This circuit breaker has an electronic trip unit, ET 1.0. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT M circuit breakers are available in 2 and 3-pole unit mount or I-Line construction. This unit has lugs on both the line and load sides. This PowerPacT M, 350A, 3 pole, circuit breaker has an interrupting rating of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT M circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.

Manuals & Documentation
Catalog Number MJL36350
Manufacturer Schneider Electric
Brand SQUARE D
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Actuator Operating handle
Application Distribution;HACR rated
Color Black
Connection Lugs, load;lugs, line; 3 x AWG 3/0...3 x 500 kcmil aluminium/copper
Frequency Rating 50/60 Hz
Number of Poles 3
Special Features 1
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=431109&lang=en-us
UPC 785901879947
GTIN 00785901879947
Item Type Circuit breaker
Width 8.27
Width UOM Inch
Height 12.86
Height UOM Inch
Depth 8.05 IN
Trip Type Electronic, basic, ET 1.0,
