Telemecanique

ZCMD21M12 ZCMD 2-Pole Fixed Limit Switch Body, 1CO Contact, For Use With XCMD and ZCMD Series Standard Format Limit Switch, 3 A Contact

MFR:
Telemecanique Sensors
MFR #:
ZCMD21M12
UPC:
785901481898
Item #:
241765

This ZCM body/contact assembly with connector has standard contacts and a Zamak body. It has 1 x co snap action contacts and a M12 4-pin connector. It can be matched with any head, actuator or connector from the XCKD, XCKP and XCKT ranges.

Manuals & Documentation
Catalog Number ZCMD21M12
Manufacturer Telemecanique Sensors
Brand Telemecanique
Warranty Description Contractual Warranty:18 months
Country of Origin Mexico
Made in USA No
Action Snap action
Amperage Rating 3
Application XCMD
Connection Male connector M12, 4 pins
Contact Configuration 1 C/O
Number of Poles 2
Operating Cycles 5000000 CYCLES, DC-13 24 V, 3 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 48 V, 2 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C-5000000 CYCLES, DC-13 120 V, 1 W 60 CYC/MN 0.5 IEC 60947-5-1 APPENDIX C
Special Features FIXED
Standard IEC, UL LISTED, CSA
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=880314&lang=en-us
UPC 785901481898
GTIN 03389110299144
Item Type Limit switch body
Size 0.63
Voltage Rating 0.1 A 250 V, DC-13 EN/IEC 60947-5-1 APPENDIX A-1.5 A 240 V, AC-15 EN/IEC 60947-5-1 APPENDIX A
