Lutron

EC3DT418KU2S EcoSystem Type K Digital Dimming Ballast, T4 Lamp, 18 W Lamp, 120/220/240/277 VAC, Programmed/Rapid, 0.95 Ballast Factor

MFR:
Lutron Electronics
MFR #:
EC3DT418KU2S
UPC:
027557638692
Item #:
230030
Manuals & Documentation
Catalog Number EC3DT418KU2S
Manufacturer Lutron Electronics
Brand Lutron
Application Lighting Control
Color White
Dimmable Yes
Frequency Rating 50/60 HZ
Lamp Type T4 4-Pin Quad tube or Triple tube Fluorescent
Mounting Fixture
Special Features Provides high-performance dimming for any compact fluorescent application. Offers continuous flicker-free dimming from 100% to 5 %, providing both energy savings and lighting flexibility. Compatible with Energi Savr Node with EcoSystem devices, GRAFIK Eye QS with EcoSystem connection, PowPak dimming module with EcoSystem connection, and Quantum systems, allowing for integration into an existing/planned EcoSystem lighting control system. Supports standard 3-wire line-voltage phase control technology. Programmed rapid start design ensures full-rated lamp life while dimming and cycling. Lamps turn on to any dimmed level without flashing to full brightness. Low harmonic distortion throughout the entire dimming range. Frequency of operation ensures that ballast does not interfere with infrared devices. Inrush current limiting circuitry eliminates circuit breaker tripping, switch arcing, and relay failure. Ultr-quiet operation. Protected from miswires of any input power to control lead, or from lamp leads to each other and/or ground. End-of-lamp-life protection circuitry ensures safe operation throughout entire lamp life. Nonvolatile memory restores all ballast settings after power failure. 100% compatible with all Lutron 3-wire fluorescent controls and EcoSystem digital controls. 100% performance tested at factory. Custom ballast factors available. Design tool and specifications can be found at www.lutron.com/ballasttool
Standard UL, CSA, Class P thermal protected, ANSI, FCC
UPC 027557638692
GTIN 00027557638692
Item Type Ballast
Length 4.9
Length UOM Inch
Width 3
Width UOM Inch
Height 1.29
Height UOM Inch
Thermal Protection Class P
Voltage Rating 120/220/240/277
Wattage 18 W
Power Factor Greater than 0.95
