XCSDMP7012 Preventa 3-Direction 3-Pole Non-Contact Standard Safety Interlock Switch, Coded Magnetic Actuator, 100 mA at 24 V DC Contact, 1NO-2NC Contact, Rhodium Contact
- MFR:
- Telemecanique Sensors
- MFR #:
- XCSDMP7012
- UPC:
- 785901971993
- Item #:
- 20980
XCSDMP7012 Preventa 3-Direction 3-Pole Non-Contact Standard Safety Interlock Switch, Coded Magnetic Actuator, 100 mA at 24 V DC Contact, 1NO-2NC Contact, Rhodium Contact
- MFR #:
- XCSDMP7012
- UPC:
- 785901971993
- Item #:
- 20980
This XCSDMP Coded Magnetic Safety Switch is designed for use as a safety interlock switch for guard door or protective casings monitoring and position detection on machines with low inertia. It has 1 normally open and 2 normally closed staggered contacts in presence of magnet + one Led. It has a rectangular design with a 2 meter with PVC cable connection, allowing for flexible installation. Its B10D reliability data is 50 000 000. Its IP66 / IP67 degree of protection makes it ideal for heavy duty use in harsh conditions. It also complies with EN/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14 standards. When associated and correctly connected to an appropriate safety control unit, it conforms to category 4, performance level PL e, SIL 3 as described in EN/ISO 13849-1, EN/IEC 61508.
Manuals & Documentation
| Catalog Number | XCSDMP7012 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | Unknown |
| Made in USA | No |
| Connection | Pre-cabled |
| Contact Configuration | 2 NC + 1 NO |
| Enclosure | THERMOPLASTIC PBT |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=859064&lang=en-us |
| UPC | 785901971993 |
| GTIN | 03389110971996 |
| Item Type | Coded magnetic switch |
| Size | 88 x 25 x 13 mm |
| Voltage Rating | 24 |
