K656DRG Elastimold 600 Insulated Deadbreak Cap With Test Point Housing, 15/25 kV, 600 A, For Use With 600 Series Separable Cable Joint, EPDM Rubber
- MFR:
- ABB - Installation Products
- MFR #:
- K656DRG
- UPC:
- 783786635511
- Item #:
- 194234
K656DRG Elastimold 600 Insulated Deadbreak Cap With Test Point Housing, 15/25 kV, 600 A, For Use With 600 Series Separable Cable Joint, EPDM Rubber
- MFR #:
- K656DRG
- UPC:
- 783786635511
- Item #:
- 194234
Manuals & Documentation
| Catalog Number | K656DRG |
| Manufacturer | ABB - Installation Products |
| Brand | Elastimold |
| Country of Origin | United States |
| Made in USA | Yes |
| Application | The insulated cap is designed to insulate, shield, and water seal 15/25kV, 600 Amp IEEE Std. 386 bushing interfaces. Units have a capacitance test point which can be used to check if the system is energized. A threaded stud attachment is standard |
| Material | EPDM Rubber |
| Special Features | 15/25kV, 600 Amp Deadbreak Rated. Molded EPDM Rubber. Provision for hotstick operation. Grounding wire attached |
| Standard | ANSI/IEEE Standard 386 |
| UPC | 783786635511 |
| GTIN | 00783786635511 |
| Item Type | Insulated Cap |
| Size | 3.13 inch (79.4 mm) Diameter of Cable Entrance, 8.31 inch (211.1 mm) Length |
