SCHNEIDER ELECTRIC

ATV12H018F1 Altivar 1-Phase Variable Speed Drive With Heat Sink, 100 to 120/115 V AC, 1.4 A, 1/4 hp, 2.83 in W x 4.02 in D

MFR:
Schneider Electric
MFR #:
ATV12H018F1
Item #:
188071

This Altivar 12 variable speed drive can feed single phase asynchronous motors. It works at a rated power up to 0.18kW / 0.25hp and a rated voltage from 100V to 120V AC. It is designed with heatsink for normal environments and fan-cooled enclosure. Transient overtorque function prevents stoppages by unjamming the machine with extra torque, when needed, this reduces downtime and maintenance costs. It features underload and overload detection, this contribute to protect your installation. The Altivar 12 drive integrates as standard the Modbus communication protocol, which can be accessed via the RJ45 connector located on the underside of the drive. It is designed for simple industry and commercial machines and appliances, such as conveyors, pumps, extractors, access barriers and treadmills. SoMove software compatibility enables saving and transfering of configurations to spare drive, reducing maintenance downtime. It features an optimized application of power and torque for ventilation and pumping applications, this allows up to 30% energy savings.

Manuals & Documentation
Catalog Number ATV12H018F1
Manufacturer Schneider Electric
Brand SCHNEIDER ELECTRIC
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Insulation Electrical between power and control
Speed Range 1-20
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=6538154&lang=en-us
GTIN 03606480071010
