SCHNEIDER ELECTRIC

LC2DT25G7 TeSys D IEC Contactor, 120/690 V AC, 300 V DC V Coil, 25 A, 4NO Contact, 4 Poles

MFR:
Schneider Electric
MFR #:
LC2DT25G7
Item #:
167861

TeSys Deca contactors have been designed for perfect integration into control systems. They can be used to create motor starters for almost any type of application. TeSys Deca contactors are available in 13 contactor ratings for inductive motor applications up to 150 full-load amps and resistive loads up to 200 amps. This reversing 4 pole IEC contactor can be mounted on DIN rail or mounted directly to a panel. Contactor has four normally open power contacts. Power contacts have a 25A resistive load rating. Contactor is supplied with a 120 VAC 50/60 Hz coil. Contactor has one normally open and one normally closed auxiliary contact built-in as standard. The NC contact is mirror certified. Screw clamp terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The contactor is 3.35 inches tall, 3.54 inches wide and 3.54 inches deep. It weighs 1.61 lbs. Contactor is certified to UL, CSA, IEC, CCC, EAC and Marine standards.

Manuals & Documentation
Catalog Number LC2DT25G7
Manufacturer Schneider Electric
Brand SCHNEIDER ELECTRIC
Warranty Description Contractual Warranty:18 months
Country of Origin United States
Made in USA Yes
Application Resistive load
Coil Voltage 120 V AC 50/60 Hz
Contact Configuration 1 NO + 1 NC
Standard UL;CSA;RINA;GOST;CCC;DNV;LROS (Lloyds register of shipping);GL;BV;UKCA;CB
RoHS URL https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=628802&lang=en-us
GTIN 03389110515886
Item Type Changeover contactor;LC2D
