LC2K0601F7 TeSys K K-Line LC2K IEC Contactor, 110/690 VAC V Coil, 20 A, 3NO Contact, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- LC2K0601F7
- Item #:
- 147131
LC2K0601F7 TeSys K K-Line LC2K IEC Contactor, 110/690 VAC V Coil, 20 A, 3NO Contact, 3 Poles
- MFR #:
- LC2K0601F7
- Item #:
- 147131
LC2K0601F7 is a compact 3-pole TeSys K reversing contactor from Schneider Electric for motor applications. Rated 6A AC-3 2.2kW@400V, it includes a 110V 50/60Hz AC coil, 2NC auxiliary contacts, a mechanical interlock and pre-wired reversing circuit. LC2K0601F7 is a 3-pole TeSys K reversing contactor from Schneider Electric for simple motor applications rated up to 2.2kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it is assembled with a mechanical interlock and a pre-wired reversing circuit. It includes a 110V 50/60Hz AC coil and 2NC built-in auxiliary contacts. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 90mm wide, for DIN-rail and panel mounting. Assembled with mechanical interlock and pre-wired reversing circuit. Provides a 110V AC coil compatible 50/60Hz and 2NC built-in auxiliary contact. Can be completed with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K).
Manuals & Documentation
| Catalog Number | LC2K0601F7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Application | Motor control |
| Coil Voltage | 110 V AC 50/60 Hz |
| Contact Configuration | 1 NC |
| Standard | CB Scheme;CCC;UL;CSA;EAC;CE;UKCA |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=629248&lang=en-us |
| GTIN | 03389110429411 |
| Item Type | Reversing contactor;LC2K |
