LC1K0901G7 TeSys K K-Line IEC Contactor, 120/690 VAC V Coil, 9/16/20 A, 3NO Contact, 3 Poles
- MFR:
- Schneider Electric
- MFR #:
- LC1K0901G7
- Item #:
- 14617
LC1K0901G7 TeSys K K-Line IEC Contactor, 120/690 VAC V Coil, 9/16/20 A, 3NO Contact, 3 Poles
- MFR #:
- LC1K0901G7
- Item #:
- 14617
LC1K0901G7 is a compact 3-pole TeSys K contactor from Schneider Electric for motor applications. Rated 9A AC-3 4kW@400V, it includes a 120V 50/60Hz AC coil and 1NC auxiliary contact. LC1K0901G7 is a 3-pole TeSys K contactor from Schneider Electric for simple motor applications rated up to 4kW@400V. Very compact, DIN-rail compatible, with connections by screw clamp terminals, it includes a 120V 50/60Hz AC coil and 1NC built-in auxiliary contact. Available worldwide, it complies with multi-standards (IEC, UL, CSA, CCC, EAC, Marine). Very compact, 45mm wide, for DIN-rail and panel mounting. Provides a control circuit compatible with 50Hz and 60Hz supplies and 1NC built-in auxiliary contact. Optimized for simple power applications. Can be completed with auxiliary contact blocks (LA1K, LA2K) and thermal relays (LR2K).
Manuals & Documentation
| Catalog Number | LC1K0901G7 |
| Manufacturer | Schneider Electric |
| Brand | SCHNEIDER ELECTRIC |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Application | Motor control;resistive load |
| Coil Voltage | 120 V AC 50/60 Hz |
| Contact Configuration | 1 NC |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=622748&lang=en-us |
| GTIN | 03389118014824 |
| Item Type | Contactor;LC1K |
