XCSM3702L5 Preventa Miniature Safety Limit Switch, 240 V AC, 5 A, Roller Plunger Actuator, 1NO-2NC Contact, 3 Poles
- MFR:
- Telemecanique Sensors
- MFR #:
- XCSM3702L5
- Item #:
- 139120
XCSM3702L5 Preventa Miniature Safety Limit Switch, 240 V AC, 5 A, Roller Plunger Actuator, 1NO-2NC Contact, 3 Poles
- MFR #:
- XCSM3702L5
- Item #:
- 139120
This XCSM Miniature Safety Limit Switch has a roller plunger, a Zamak body and head and a 5 meter pre-cabled. It has 1 normally open and 2 normally closed break-before-make (slow break) contacts. Its B10D reliability data is 50 000 000. It has IK06 impact resistance and IP66 / IP67 / IP68 degree of protection, makes it ideal for heavy duty use in harsh conditions. It also complies with EN/ISO 14119, EN/IEC 60204-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No 14 standards. When associated and correctly connected to an appropriate safety control unit, it conforms to Category 4, performance level PL e, SIL 3 as described in EN/ISO 13849-1, EN/IEC 61508.
Manuals & Documentation
| Catalog Number | XCSM3702L5 |
| Manufacturer | Telemecanique Sensors |
| Brand | Telemecanique |
| Warranty Description | Contractual Warranty:18 months |
| Country of Origin | France |
| Made in USA | No |
| Action | Lateral approach;Slow-break, break before make;By 30 Degrees cam |
| Actuator | Roller plunger |
| Application | PLUNGER HEAD |
| Connection | Pre-cabled |
| Contact Configuration | 1 NC + 1 NC + 1 NO |
| Mounting | By The Body |
| Special Features | Plastic protective cover, secured by 5-lobe socket head safety screw |
| Standard | 25 GN 10-500 HZ)IEC 60068-2-6,25 GN 18 MS IEC 60068-2-27,CSA-UL,IK06 EN 50102,IP66 IEC 60529-IP67 IEC 60529-IP68 IEC 60529,UL 508-EN/IEC 60204-1-EN 1088-EN/IEC 60947-5-1-CSA C22.2 NO 14,CLASS I NF C 20-030-CLASS I EN/IEC 61140 |
| RoHS URL | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=859672&lang=en-us |
| GTIN | 03389110244199 |
| Item Type | Safety limit switch |
| Size | 0.63 |
| Operating Temperature | -25-70 A Degrees C |
